BD175

Suitable Conditions

Medium and long mileage trucks running on paved and highway roads

Low Heat Generation

High Wear Resistance

Excellent Grip

Economy and Environment Friendly

Suitable

Origin	Size	PR	LI/ SS	Standard Rim	Max. Load				Pressure				Tread Depth (mm)	Overall Diameter (mm)	Section Width (mm)
					(kgs)		(lbs)		(kPa)		(PSI)
					S	D	S	D	S	D	S	D
CN	11R22.5	16	148/145L	8.25	3150	2900	6940	6395	850	850	123	123	20.0	1059	279
CN & VN	11R22.5	16	146/143K	8.25	3000	2725	6610	6010	850	850	123	123	20.0	1065	279
CN	12R22.5	18	152/149K	9.00	3550	3250	7825	7165	930	930	135	135	20.0	1096	300
VN	12R22.5	18	152/149L	9.00	3550	3250	7830	7160	930	930	135	135	20.0	1096	300
CN	13R22.5	18	154/151K	9.75	3750	3450	8270	7605	830	830	120	120	20.5	1124	320
CN & VN	205/75R17.5	14	124/122L	6.00	1600	1500	3525	3310	750	750	110	110	15.0	753	204
CN & VN	215/75R17.5	16	135/133L	6.00	2180	2060	4805	4540	860	860	125	125	15.0	767	211
CN & VN	235/75R17.5	18	143/141L	6.75	2725	2575	6005	5675	860	860	125	125	15.0	797	233
CN	225/70R19.5	14	128/126L	6.75	1800	1700	3970	3750	760	760	110	110	15.0	811	226
CN & VN	245/70R19.5	18	144/142J	7.50	2800	2650	6175	5840	900	900	130	130	15.5	839	248
CN	265/70R19.5	18	143/141J	7.50	2725	2575	6005	5675	900	900	130	130	15.5	867	262
CN	255/70R22.5	16	140/137L	7.50	2500	2300	5510	5070	830	830	120	120	15.5	930	255
VN	275/80R22.5	16	146/143L	8.25	3000	2725	6610	6005	830	830	120	120	22.0	1012	276
CN & VN	295/80R22.5	18	152/149M	9.00	3550	3250	7825	7165	900	900	130	130	22.0	1044	298
VN	315/70R22.5	18	156/150L	9.00	4000	3350	8820	7385	900	900	130	130	20.0	1014	312
CN & VN	315/80R22.5	20	156/153L	9.00	4000	3650	8820	8045	850	850	125	125	23.0	1076	312
VN	315/80R22.5	20	156/150(154/150)L(M)	9.00	4000	3350	8820	7390	850	850	125	125	23.0	1076	312
CN	315/80R22.5	22	158/156K	9.00	4250	4000	9370	8820	900	900	130	130	23.0	1076	312

S=Single D=Dual; 1inch=25.4mm 1kPa=0.142psi 1KG≈2.2lbs
